Wenzhou Starry Valve Co., Ltd. is one of the most reliable manufacturers and suppliers of cast steel ball valve in China. We are committed to providing high quality customized valves with low price. If you're going to buy bulk durable cast steel ball valve, welcome to get quotation from our factory.
| Size Range | DN15 ~ DN1200 (NPS 1/2" ~ 48") |
| Pressure Rating | ANSI Class150, Class300, Class600, Class900, Class1500; PN16 ~ PN100 |
| Temperature Range | -40℃ ~ 425℃ (Carbon Steel); -196℃ cryogenic optional; high-temperature metal seal up to 500℃ |
| Connection Type | Flanged RF, Butt Weld, Threaded NPT/BSP, Lug & Wafer optional |
| Body Material | ASTM A216 WCB Carbon Steel, A352 LCB Low-temperature Steel, CF8/CF8M Stainless Steel |
| Sealing Type | Soft seal (PTFE/RPTFE/Viton) zero leakage; Metal hard seal for high temp & scouring service |
| Operation Type | Manual lever, worm gear, electric, pneumatic, hydraulic actuation optional |
| Execution Standard | API 6D, API 607 Fire-Safe, ASME B16.34, ASME B16.10, API 598, MSS-SP-25 |
| Structural Feature | Cast steel ball valve adopts integral cast WCB carbon steel body with floating ball or trunnion mounted ball structure. Full bore or reduced bore design optional, featuring straight-through low-resistance flow channel. Spring-loaded seat sealing structure provides automatic wear and temperature deformation compensation, achieving stable bubble-tight shutoff. Anti-static device and blow-out proof stem ensure operational safety. Fire-safe design complies with API 6D standard, effectively preventing medium leakage under fire accident conditions. Integral cast body owns high rigidity and pressure resistance, suitable for long-term stable operation of high-pressure industrial pipelines. |
| Suitable Media | Water, steam, natural gas, crude oil, refined oil products, compressed air, light chemical fluid and general industrial media. Widely applied in petroleum, chemical industry, power plant, urban pipeline networks, heating systems and long-distance oil & gas transmission projects. |
Features
Cast steel ball valve adopts standard A216 WCB carbon steel integral casting, with uniform internal structure, high pressure resistance and excellent mechanical toughness. It effectively resists pipeline pressure impact, thermal deformation and medium scouring, far exceeding the strength level of ordinary ductile iron valves. Low-temperature LCB material configuration is available to adapt to ultra-low temperature working environments, ensuring no brittle fracture failure.
Equipped with high-precision polished ball core and elastic spring-loaded sealing seat. Soft seal version achieves complete zero leakage and excellent sealing stability; upgraded metal hard seal structure adapts to high temperature, high pressure and particle-containing media. Bidirectional equal pressure bearing design eliminates flow direction restriction, facilitating on-site pipeline installation and layout.
Built-in anti-static device conducts static electricity generated by friction between ball core and sealing seat to avoid static explosion risk of flammable media such as natural gas and oil. API 607 fire-safe structure adopts graphite auxiliary sealing, which can maintain basic sealing performance under high-temperature fire conditions, meeting strict safety standards of petrochemical and gas transmission projects.
Full-bore ball valve realizes straight-through pipeline with almost no flow resistance, ensuring maximum medium transmission efficiency and reducing pipeline energy consumption. Reduced-bore type features compact structure and cost advantage, suitable for general flow regulation and cut-off working conditions. 90-degree quick switching realizes fast opening and closing, improving pipeline operation efficiency.
Floating ball structure is suitable for medium and low pressure working conditions with flexible operation and low torque; trunnion mounted ball structure adapts to large-diameter and high-pressure heavy-duty pipelines with stable bearing and long service life. Multiple connection methods and driving modes fully cover various industrial pipeline design requirements, with strong engineering versatility.
Typical Application Equipment
- Petrochemical oil refining, chemical process and flammable medium pipeline systems
- Natural gas transmission, gas distribution station and urban gas pipe network projects
- Power plant steam, circulating water and auxiliary fluid control pipelines
- Industrial high-pressure, high-temperature and fire-safe required isolation pipelines
- Long-distance oil and gas transportation and energy pipeline engineering
Working Principle & Application Notes
Cast steel ball valve drives the spherical core to rotate 90 degrees through handle or actuator to realize pipeline opening, closing and flow regulation. When the ball hole is parallel to the pipeline, the valve is fully open for smooth medium circulation; when rotated 90 degrees, the solid spherical surface completely blocks the flow channel to realize tight cut-off. The spring seat automatically compensates sealing clearance caused by pressure and temperature changes to ensure long-term stable sealing. Soft seal type is prohibited for ultra-high temperature and hard particle media; particle scouring working conditions must select metal hard seal configuration. Flammable and explosive media must be equipped with anti-static and fire-safe structure. Please confirm bore type, pressure class, sealing form and driving mode before ordering
